I recently had an epiphany about how to grow Bryopsis more efficiently. In retrospect, it was pretty obvious, and I wonder why it took 2 years to get to this point.
It seemed as though culturing adequate Bryopsis was under control. However, there’s nothing like 6+ weeks of travel to turn things upside-down. I had hired a service to come in and keep things going while I was away, but their primary task was to prevent biological meltdown, or worse, a big salty disaster that would have me forever on the naughty list of the facilities people. I am happy to say, there were no smelly or wet disasters.
Unfortunately, I was not there to give the algae cultures the kind of attention they need, and by the time I was back in the office, the system was overrun with Derbesia, and the slugs had devoured the Bryopsis that I had left for them. The 20-gallon slug tank and both algae culture tanks were full of felty, green hair algae. In retrospect, I should have taken photos, but I was more focused on cleaning up the mess and getting ready to teach a summer class.
Over a week or so, I pulled out the algae tanks off the system, cleaned out at least two pounds of green glop, salvaged the remaining Bryopsis, and set the tanks back up. Somewhere along the line, I came across a few posts about “algae reactors,” cylindrical chambers with water flowing through and some sort of light source. My first thought was “maybe I should buy one of those things.” Then I remembered that I had two media reactors sitting idly in the basement. They are clear cylinders, designed to have water flow through them, which is exactly what I wanted.
The amount of Bryopsis remaining was so small that it didn’t seem worthwhile to have two algae tanks. Instead, I shut down the 10-gallon tank and stuck some of the remaining algae into a reactor. The reactor was hooked up to one of the valves, and connected to the drain, and sat under the grow light where the 10-gallon tank had been.
Within a week or so, it became clear that the experiment was working, so I added the second reactor. I had enough Bryopsis to harvest some for the slugs, and the culture in the first reactor had seeded a sponge that I could use to start the second reactor.
It was working. Time to make things a little less clumsy. I built a rack from 3/4″ PVC, setting the reactors at an angle to optimize the connections to the input valves and drains.
Things went so well, I begged a few unused reactors from local aquarists. This one is from Alan (of unidentified algae fame), and I have one more waiting in the wings.
At this point, it was clear that my former method of rearing Bryopsis in aquaria was not very efficient. Raising Bryopsis in reactors allows me to play with growth parameters, like flow and nutrients, much more easily. Further, keeping multiple separate cultures will make it much easier to eradicate unwanted algae. At some point, it should be straightforward to maintain cultures free of unwanted algae and invertebrate pests (I am all for biodiversity, except when it eats slug larvae) by UV sterilizing the water going into the chambers.
As far as I can tell, this was a successful experiment, so I converted the 15 gallon algae tank into the second slug tank, shutting down the 10-gallon slug tank.
When I walked in today, the system had two slug tanks (top and middle left), and one remaining algae tank (top right)
Five hours of cleaning and rearranging later, there were two slug tanks and three algae reactors. In the process, the system now has two fewer circulation pumps and one fewer light fixture.
In the future, you can expect a few more reactors. Now it’s time to play with parameters to maximize algae growth. Maybe we’ll finally see some consistent egg production from the slugs.
Every 5 or 6 years, we end up exploring someplace a little more exotic. This year, we decided to go to Madagascar, and we arranged for a driver and accommodations for about 10 days of overland travel and saw some incredible people, landscapes, and wildlife. We’re still sorting through the photos of lemurs, chameleons, villages, and vistas, and it is likely to take some time.
Of course, you don’t come to this web site for the lemurs.
Because we were traveling all the way to an island in the tropical Indian Ocean, I pushed for a stretch of diving at the end. When we were planning the trip, I asked our tour operator, Cactus Tours (an excellent Madagascar-based company) to arrange for some diving at the island of Nosy Be, at the north end of Madagascar. We ended up spending a few days in Nosy Be, and had three days and two night of diving on a sailing catamaran.
After bouncing around in a four-wheel drive for over a week, it was pure luxury to be on the boat. For just the two of us, there was a driver, cook, and a very experienced and knowledgeable dive master, all arranged through Madavoile Cruises. We had six excellent dives, and were completely blown away by the diversity of corals, fish and invertebrates.
Our dive guide, Nicolas, figured out pretty quickly that I wanted to see nudibranchs and sea slugs, and he did not disappoint. The photos below were taken with an Olympus Tough TG-4 camera, which is rated to 50 feet without a housing. Because the housing was clumsy, we took the unhoused camera as deep as 65 feet, which worked just fine despite its increasingly strident warnings. Identifications are based largely on a digital version of Gosliner et al’s “Nudibranch and Sea Slug Identification” and the Sea Slugs from Reunion Island Web site, which is an excellent reference for the southwest Indian Ocean. Please let me know if you believe a species to be misidentified.
Although we saw plenty of Caulerpa, Halimeda and other macroalgae, and looked very hard for Elysia, we came up empty. At Nosy Sakatia, we spent our last morning snorkeling with the turtles before we dove, and I was pleased to see a wide expanse of turtle grass (Thalassia) and manatee grass (Syringodium), which had some excellent growths of Halimeda incrassata.
Unfortunately, I did not get to spend hours searching the seagrass beds. Watching the biggest green turtles I had ever seen graze right in front of me was a nice consolation. It is hard to get a sense of just how big these monsters are from a photograph.
I did find one sacoglossan, Plakobranchus ocellatus, on the reef at Sakatia Arch. Unfortunately, the camera housing I was using for the dive had fogged, so it is a lousy photo. Just not the trip for sap-sucking slugs, I guess.
In addition to the plentiful slugs, there were quite a few flatworms pretending to be nudibranchs. All were in the genus Pseudoceros, and all were found in Humann and Deloach’s Reef Creature Identification book, which has an impressive section on flatworms.
As described in the previous post, I had very modest goals for this summer in Bahia. Because I am getting more interested in the role of kleptoplasty in chemical defense, I thought it would be worth assessing the palatability of Elysia diomedea. Some Elysia species are known to taste bad because of chemicals assimilated from their food plants (see, e.g., Rasher et al., described in this post). E. diomedea is known to produce interesting derivatives of plant compounds (e.g., Ireland et al., 1978, J. Am. Chem. Soc. 100:1002), but, as far as I can tell, there is no evidence regarding the slugs’ palatability.
Fortunately for me, there is a relatively easy way to get a quick sense of their palatability. When snorkeling at the field station, one is generally followed by a small parade of large bullseye puffers (Sphoeroides annulatus) waiting for tasty morsels to be stirred up. What would happen if I dropped a slug in the water column and allowed the fish to eat it? One might expect a puffer to eat anything.
After a day in the field, I had time for a snorkel, so it was a perfect opportunity. After a short survey along the subtidal, I found a few Elysia in a small bunch of Codium (surprise!). I pulled out this little beauty, apologized to her and carried her to the surface.
If you click the link below for the short video (note: large-ish file), it is pretty clear that the puffer does not find the little Elysia to its liking.
Not only one, but three puffers rejected the Elysia. After the first spat out the slug, a second tried it, then a third. In no case did one of the puffers as much as chew, they rejected it as soon as it was in their mouths. Very good for the slug, and suggests that it may be something secreted in the mucus that repels the fish. One might also conclude that puffers don’t learn from their friends, since each had to try it.
Based on one slug (but three puffers), we can tentatively conclude that E. diomedea tastes bad. Are the bad tasting compounds derived from products made by the kleptoplasts?
Nature is perverse.
We’re back in Bahia de los Angeles, on the east coast of Baja California, Mexico. For the two previous years, I have had to suffer for a while before finding any Elysia diomedea. It was rather nerve wracking, because I needed them for research projects each of those years.
Because of time constraints, my goals this year are to help my friend, Dr. Drew Talley, with his long term research, and to discuss plans for student Elysia projects in summer 2018 with Ocean Discovery Institute.
We had some complications at the border, because the Mexican authorities had some reservations about some equipment that was being used by one of the other research groups. We were allowed to proceed after a few hours dealing with paperwork, but were delayed to the point that we had to stop along the way for the night.
We arrived without further incident, unloaded equipment and belongings, started setting up the station, had a great meal in town, we went to bed for the night. It was amazing to be back under all the stars, listening to the ocean and the occasional breathing of a marine mammal.
We woke up to a classic sunrise, and soon we were on the islands, setting traps for insect surveys and savoring the bay and the scenery.
After returning to the station, we ran some errands, followed by a little open time to get in the water. Although I may try a few extremely simple preliminary experiments, my work here does not depend on finding them. Naturally, that means they were abundant in the shallows in front of the station. I found the first within five minutes, and saw at least six within the half hour allotted for the survey.
They looked darker than the slugs we found last summer, but, as was true last summer, all were on or near Codium.
Keeping fingers crossed for a chance to test some ideas about chemical camouflage.
Just when I thought I had it all figured out.
After struggling for way too long, I finally got reliable growth of Bryopsis in the algae culture tanks by providing strong lighting, balanced nutrients, along with very intense water movement. Bryopsis grew well, although Derbesia also started to thrive and needed periodic removal, so I figured I was close to the magic formula.
Imagine my surprise when Bryopsis started to thrive, largely without contamination by dinoflagellates or Derbesia, in the slug culture tanks. In the 20 gallon long, the algae that was transferred on the plastic racks started to grow and spread, despite constant grazing from the resident E. clarki. In the 10 gallon, a few scraps growing on some of the macroalgae grew to fill almost half the tank.
This has made the single E. crispata very happy. She has grown considerably, and her color is amazing. Will post a photo when she comes out of the algae far enough to be photographed.
The tanks are all plumbed together, so they all receive the same nutrient input. The slug tanks receive somewhat less light than the algae culture tanks. The spectrum of the lights in the slug tanks is broader, with more green, yellow and UV, mostly because that is nicer for my eyes when I look at the tanks. Finally, the circulation is considerably less intense. The algae tanks are blasted with propeller pumps and wavemakers, while circulation to each of the slug tanks is only provided by a single Maxi-Jet 600 (600 liters per hour output), with the intake slug-proofed by a strainer and sponge, and the output directed through a Hydor Flo to provide swirling motion.
Because even these relatively small pumps give the slugs a bit of a wild ride, they are only turned on for 15 minutes of every hour. Quick summary: despite my beliefs to the contrary, it is possible for Bryopsis to grow strongly with modest water movement.
Although I am pleased that there is now abundant food for the slugs, it does bother me that I still do not understand all of the factors affecting growth of Bryopsis. Previously, Bryopsis struggled in conditions that were largely similar. If I get a chance before leaving for Baja this week, I’ll make yet another deep dive into the system logs to determine which parameters may have changed. The luxuriant growth has emboldened me to order a few more E. clarki, so that the colony can be going full steam by the end of the summer.
To many, this post is akin to “how to give fleas to your dog,” or “how to grow ragweed.” Bryopsis is a benthic (substrate-associated) genus of algae that most aquarists dread seeing in their tanks. Bryopsis can thrive in reef aquaria, to the point that it can smother and kill corals. Many methods of eradication have been explored, including near-toxic levels of magnesium, and the anti-fungal medication fluconazole.
On the other hand, I really want the stuff. As far as I can tell, it is the favorite food of Elysia clarki. E. clarki will eat other macroalgae, such as Penicillus, Avrainvillea or Halimeda, but, given the choice, they will go straight for Bryopsis and stay there. Further, they have consistently produced eggs only at times when they have had unlimited availability of Bryopsis. One of my primary goals is to maintain a self-sustaining colony of slugs, so I very much want a constant, adequate supply of algae.
I’d be perfectly happy if I could count on the outbreaks of local aquarists to supply my needs. Unfortunately, sources have been spotty. My primary source, Justin, who had a beautiful outbreak in a 500-gallon tank, unfortunately managed to get his infestation under control. He swears the controlling factor for him is the level of phosphate; if PO4 levels creep up, he gets an outbreak. Others have provided quality material as well, but not as consistently. Yet others have offered species that turn out not to be Bryopsis. The take home lesson is that people who are trying to eradicate something are not the most dependable source.
How hard can the stuff be to grow? It is a pest, after all. Like any aquatic plant, it needs light, nutrients, and circulation. It gets a little more difficult when you try to provide for the plants’ requirements on a consistent basis. As far as I can tell (and PLEASE email or comment if I am wrong), nobody has published specific requirements of Bryopsis for PAR (photosynthetically-available radiation), macronutrients (e.g., carbon, nitrogen, phosphorous), or micronutrients (like iron, copper and cobalt). When marine aquarists have outbreaks, much of the nutrient load is derived from fish food (well, really fish poop), which is not measured. In fact, most reef aquaria don’t have Bryopsis outbreaks, which suggests that the unlucky few have managed to combine all the right ingredients. For a constant supply of Bryopsis, I need to provide for all of its needs.
If I wanted to grow phytoplankton, the single-cell, free-floating relatives of Bryopsis, I would be in luck. Because of the important role of phytoplankton in our oceans, and because there is a growing industry using them to generate hydrocarbons from sunlight, growing conditions have been explored and published at length. The most popular formula is Guillard’s F/2, so named because it consists of his formula F diluted to 50% (Guillard & Ryther, 1962, Can. J. Microbiol. 8:229), is readily available through suppliers such as Florida Aqua Farms, or even Ebay. The formula provides a balanced blend of nitrogen and phosphorous (with an option to add silicon if you want to grow diatoms), along with a mix of trace elements and vitamins. Mix it up, add a starter of the phytoplankton of your choice, bubble in some CO2 as a carbon source, and you’ll soon have a thriving culture of green water.
I started dosing the Florida Aqua Farms version (“Plant Fuel Too”) almost a year and a half ago, using the complete dry mix (minus silicates). The Bryopsis started to look darker and happier pretty quickly. Perhaps unsurprisingly, there was also a phyoplankton bloom that turned the water green and generated a layer of green scum on the surface of the water. Also, the added nutrients seemed to increase levels of nuisances like cyanobacteria (a.k.a., red slime algae). That would have all been tolerable, but the biggest sticking point was that Bryopsis would go through cycles of boom and bust, which is not conducive to long-term management of a slug colony. I needed to get the right balance of nutrients that would get the Bryopsis to grow maximally and out-compete the species I don’t want.
With all of the possible factors (e.g., light, circulation, temperature, nutrients) to be within the right ranges, there were a lot of variables to play with:
- Levels of light seemed to be within the range I observed in tanks with steady outbreaks, so I left that alone.
- Bryopsis always grows well in the areas with the strongest water flow (e.g., pump outlets). I am not sure why, maybe it keeps other algae from settling on it, but I increased the flow to ridiculous levels in the 15-gallon primary culture tank by combining a power filter Aquaclear AC70), powerhead (Hydor 2450) and wavemaker (MaxSpect Gyre XF130) that were all rated for tanks 3-5 times the size.
- I plunged back into the literature to try to find papers examining the nutrient requirements of benthic macroalgae, rather than phytoplankton. After a little digging, I found that species related to Bryopsis demand much more carbon and nitrogen, and are not as dependent on phosphorous (e.g., Atkinson and Smith, 1983, Limnol. Oceanogr. 28:568; Pedersen and Borum, 1997, Mar. Ecol. Prog. Ser. 161:155).
In order to separate the variables a bit better, I started using Florida Aqua Farms original “Plant Fuel,” which contains all of the trace elements and vitamins, but no nitrogen or phosphate. That would allow me to play with levels of trace elements, N, and P separately. I also added a source of carbon. Because white vinegar is cheap, always available, and is readily broken down into CO2 by bacteria, it seemed like a good choice.
By adjusting the relative input of all four ingredients (C, N, P and trace elements), combined with very high flow in the algae culture tank, I was able to get significantly better growth. The final improvement was something that I had not expected to have such an impact: rebuilding the system. Within about a week of the big move, the algae was thriving on the racks of plastic eggcrate I was using as a substrate. I suspect that the 50% water change and improvements to circulation in the new system played a large part in the improved growth.
By growing on plastic racks, Bryopsis cultures can be moved to slug tanks to be consumed, and then removed for regrowth.
So we’re making forward progress. We are controlling the growth of food algae to the point where it seems to be sustainable. As a side benefit, the other macroalgae are also thriving. For example, the three deep green Penicillus in the photo below are new sprouts from the ratty old plant in the center.
At the moment (and likely to change) the system receives major elements at the (molar) ratio of 150:30:1 C:N:P. This is roughly in the range reported for other macroalgae, and does not support much growth of cyanobacteria or phytoplankton. In other words, it looks like I am providing nutrients at about the rate at which the are being consumed by the desired algae.
- N: dosing KNO3 (13.9% N); stock = 80 grams/liter (g/l), diluted to 20 g/l; dosing 80 milliliters/day (ml/d); that equals 0.222 g/d of N, or 0.0159 moles/day
- P: Dosing KH2PO4 (22.8% P); stock = 11.6 g/l; diluted to 1.45 g/l; dosing 50 ml/d; 0.0165 g/d or 0.00053 mol/d
- C: from acetic acid: 5% solution (50 g/l); 48 ml/d; C = 40%; 0.96 g/d; 0.08 mol/d
- K: from KNO3 AND KH2PO4: 0.64 g/d or 0.021 mol/d
- Guillard’s F/2 trace element and vitamin solution: diluted 1:20, dosing 100 ml/d;
- I have also started adding calcium hydroxide (CaOH2, kalkwasser) to the water used to make up for evaporation to maintain Ca.
There is still plenty of room for improvement. The priority for the moment is eliminating or reducing dinoflagellates in the algae culture tanks. They do not seem to cause too much trouble in the slug tanks, but they form a slimy film on the Bryopsis in the culture tanks, presumably reducing growth, competing for nutrients, and producing toxins.
At higher magnification they are kind of pretty. Based on the shape, size and general appearance, it looks a lot like Ostreopsis ovata (Faust and Gulledge, 2002, Contr. U.S. Natl. Herb. 42: 1-144). Like many dinoflagellates, O. ovata produces toxins, some of which are toxic to mice (Nakajima et al., 1981, Okinawa Bull. Jpn. Soc, Sci. Fish. 47: 1029). The effects on slugs or other invertebrates is not known.
At the moment, I have reduced the photoperiod (the time the lights are on), and am rinsing the Bryopsis racks in clean artificial seawater periodically to reduce the population. At some point, it might be necessary to use harsher methods, such as antibiotics (metronidazole seems to affect dinoflagellates somewhat specifically) or starting a clean culture of Bryopsis and preventing entry of other species using UV sterilization.
For now, there is plentiful food for the slugs, which is a step forward.
Welcome to the Roughly Annual Solar Sea Slug Journal Club.
Today’s paper came from the Proceeding of the National Academy of Sciences a few years ago (Rasher et al., 2015, Proc Natl Acad Sci 112:12110). I came across it again when I was updating records for this site, and, because it is germane to one of my pet theories, it seemed perfectly suited for an extended discussion. You’ll see how George Harrison fits into the story later. Yes, this post will meander a bit, but the fact that you are reading the Solar Sea Slug Blog suggests you may have some time on your hands.
The paper is a very nice exploration of the interactions between herbivores and their food plants. Up here on dry land, insects tend to specialize on particular food plants, and bugs and plants have evolved together in something of an arms race. Insects use volatile chemicals produced by the plants to locate them, plants produce defensive chemicals to keep from being eaten and from being infected by insect-borne pathogens, insects develop resistance to the plant chemicals, and sometimes use them for their own defense, and so on. The authors wondered if they could identify a similar web of interactions in the marine environment.
The algae Halimeda incrassata would seem to be rather unpalatable. It produces a collection of defensive chemicals, and is highly calcified, making it a crunchy, bad tasting mouthful. Despite the defenses, Elysia tuca, a tiny and distinctively-patterned species, is commonly found on Halimeda. The interaction between E. tuca and H. incrassata allowed the authors to ask how similar the relationship between a mollusc and a marine alga is to those of insects and terrestrial plants.
In order to compare the relationship between E. tuca and Halimeda to terrestrial plant-insect interactions, the study focused on five specific questions:
1) Is E. tuca really a specialist? This is important for the development of an intimate plant-herbivore relationship.
2) Does E. tuca find Halimeda based on chemical cues?
3) What are the cues that E. tuca uses?
4) What are the ecological consequences of E. tuca feeding on H. incrassata?
5) Does Halimeda use counter-defenses to limit the damage inflicted by E. tuca.
With regard to E. tuca being a specialist, the answer was a pretty resounding “yes.” They collected specimens of about 10 species of algae and marine plants at two sites, took them to the lab, and counted the numbers of E. tuca on each. With a few exceptions (also in the genus Halimeda), E. tuca were only found on H. incrassata. Further, when given the choice between many different algae species in the lab (Fig 1A, below), or three different species of Halimeda in the lab (Fig 1B), or in the field (Fig 1C) the slugs greatly preferred H. incrassata. To test whether the slugs were following chemical cues, the experimenters soaked cotton balls in water that had held H. incrassata (Fig 1D), and found that E. tuca much preferred these to cotton balls soaked in plain seawater. With regard to the questions posed by the paper, the results indicate that 1) E. tuca is a specialist, and 2) they find their host based on chemical cues.
The next question regarded the identity of the chemical attractants from H. incrassata (which will be henceforth referred to as “Halimeda”). Compounds were extracted from Halimeda with methanol, and the individual components of the extracts were separated as described in the supplementary methods. Each fraction was tested for attractiveness to slugs using the cotton ball colonization assay described in Figure 1, above. The first compound they described, 4-hydroxybenzoic acid (4-HBA; Figure 2A, left) is found in both “vegetative” Halimeda in the normal growing stage, and in “reproductive” Halimeda that are undergoing spawning events. When 4-HBA was placed on cloth patches next to Halimeda, the plants were colonized by significantly more Elysia than to controls with cloth soaked in the solvent but no 4-HBA (Figure 2B, left panel).
The reproductive stage of Halimeda is significantly more attractive than the vegetative stage, in part because the reproductive cells (gametes) are a rich source of nutrients. When patches soaked in extract from reproductive plants were placed next to Halimeda plants, they attracted more than twice as many slugs as those from vegetative plants (Figure 2B, right). This led the authors to identify halimedatetraacetate (HTA; Figure 2A, right) a chemical compound enriched in reproductive Halimeda. It was known that HTA deters feeding on Halimeda by other species, and that E. tuca sequesters HTA in its tissues. The authors went on to show that an extract from E. tuca that contained HTA deterred feeding by predatory wrasse.
This brings us to question #4, what are the ecological consequences of E. tuca grazing on Halimeda? Surprisingly, the effects of such tiny slugs are significant. The fact that the slugs feed on reproductive structures (which have the highest HTA content) is expected to substantially reduce the plants’ fecundity. Further, when the authors manipulated the numbers of Elysia on plants in the field, those with more slugs showed less growth (Figure 3A) and more branch loss (Figure 3B). Placing E. tuca in enclosures on branches (Figure 3D) also caused more branch loss compared with enclosures with no slugs. So E. tuca can cause significant damage to Halimeda. Because H. incrassata aids the development of seagrass beds, and generates the majority of carbonate sediments (a.k.a., nice white sand) in those areas, the authors suggest that grazing by E. tuca can have ecosystem-wide consequences.
How can a small slug that sucks sap cause such dramatic loss of plant tissue? One hypothesis is that the plant self-amputates segments that have been fed upon by Elysia. The model Rasher et al. propose is that the plants are trying to avoid the introduction of pathogens by the slugs by sacrificing segments. After culturing fungi from the slugs’ radullae, which they use to pierce the plants’ tissues, they tested one fungal species they referred to as Et-2. Halimeda innoculated with the fungus dropped segments above the injection site (Figure 4A). Injection of a fungus that is a pathogen of other species did not have the same effect (Figure 4B). The data are therefore consistent with the hypothesis that loss of segments is a defensive strategy in response to feeding by E. tuca, suggesting that the answer to question #5 is also yes.
The authors conclude that the answer to all of the questions they posed is “yes,” and that marine plant herbivore interaction described above strongly resembles those in terrestrial ecosystems, despite more than 400 million years of separation between the participating species.
At some point, this paper got me thinking of a potential alternative function for kleptoplasty. Shall we meander our way there?
By the end of last summer, I was finding most of the prevailing theories regarding kleptoplasty to be rather unsatisfying. While not every aspect of biology must have a function, kleptoplasty has costs that must be offset. It takes energy to segregate and store the chloroplasts, and they must be protected from the immune system. Plus, the animals that are active in the sunlight are exposed to predation and damage from UV light. Despite these costs, Elysia is a very successful genus, with species found worldwide in the shallows of tropical and temperate seas. Therefore kelptoplasty must provide a significant benefit.
So, what good is kleptoplasty? If you buy the arguments presented by deVries et al, photosynthesis by kleptoplasts do not supply a significant portion of the animals’ energy needs. Is the energy produced by photosynthesis used to make starch or fat for use during lean times? Maybe. Could the kleptoplasts be a “living larder,” being digested when food is scarce? The animals certainly become pale when they are starved, suggesting the kleptoplasts are being broken down, but why not just digest them at the time they are eaten and turn them into fat like the rest of us do?
One idea is that the kleptoplasts are merely used as camouflage. In the case of E. diomedea, which spends a lot of its time hidden in its food plant, this seems sensible. Not so much for E. crispata, which is easily visible against hard bottom reefs, which are generally not very green. Further, it seems like there are other, less complicated ways of making or storing green pigment to match one’s surroundings. However, let’s hold that thought for a minute.
Aside from making carbohydrate from sunlight and being green, chloroplasts produce important precursors for many biochemicals (e.g., Gould et al., 2008, Ann. Rev. Plant Biol. 59:491). These could be used by the slugs for the synthesis of fats or essential aromatic amino acids for their own nutrition, or to be used for their prodigious production of eggs. Given that there is absolutely no data regarding the role of photosynthesis in egg production by Elysia, this remains an attractive hypothesis.
However, an insight I thought was particularly brilliant was that chloroplasts synthesize isopentyl diphosphate (IPP), a precursor to a wide range of things, such as chlorophylls and terpenes. Some of these compounds are expected to be smelly, and, in principle, make the slugs smell like their food. Some of the chemicals may also taste bad, rendering the soft, slow animals less palatable.
Predators of Elysia are expected to include nudibranchs, which are largely blind and find their food by smell, or fish, many of which find their prey by sight. If the chloroplasts were pumping out chemicals that gave the slugs a smell of their food, it would make it much more difficult to find them by scent. One bonus is that the green color of the kleptoplasts will also make it more difficult for visual predators, such as fish, to find the slugs. On top of that, any noxious taste would protect the slugs from predators, regardless of their hunting methods. Overall, this model seemed to have fewer caveats than any of the others.
I thought I had come up with this idea on my own. Then I rediscovered the above paper by Rasher et al. while I was updating a saved search in the Scopus database. PNAS is my Wednesday lunchtime reading, and I am sure that I was excited to come across a paper about Elysia, so I am certain that I read it when it came out. I am saddened by the fact that I forgot that I had read the paper, and assume that the paper got me thinking about kleptoplasty and chemical camouflage.
Have you figured out the connection to George Harrison yet? You have to be getting on in years or love music trivia to remember, but he produced a popular song “My Sweet Lord,” during his post-Beatles solo career. He ran into some legal trouble when the Chiffons’ record label sued him for appropriating the melody from their highly popular “He’s So Fine.” If you go online and listen to both of them, it won’t take you long to think “dang, he stole their melody.” Harrison admitted that he was very familiar with the melody, and the judge ruled that he had committed “subconscious plagiarism.” In the same way, I had no memory of even having read the Rasher paper when I was formulating ideas and researching the biosynthetic capabilities of chloroplasts. I just thought I was being terribly clever. Nonetheless, it is highly likely that the paper was somewhere in the recesses of my mind during the process. Are there any truly new ideas?
But, more importantly, how does one test this? The first step is to make some predictions, and here are a few possibilities:
- Comparison of compounds produced by food plants, normal Elysia, and Elysia in which photosynthesis is blocked will show compounds produced by plants and normal slugs that are absent or significantly less abundant when photosynthesis is blocked. All we need to do is make some extracts and find a potential collaborator who is willing to perform some gas chromatography-mass spectroscopy on a small budget.
- Elysia in which photosynthesis has been blocked will be easier to detect or more attractive to predators. Placing a predatory mollusc or fish in a Y-maze with a choice between an arm containing a control and one containing a photosynthesis-blocked Elysia might do the trick. There are plenty of hungry wrasses that we could use for the fish test, either in the lab or in Bahia. As far as predatory slugs, Navanax or Roboastra are good candidate predators for E. diomedea in Baja California.
There are likely to be more, better experiments, but the above provide a start.
The first version of the multi-tank slug system has served reasonably well, but it has had its limitations. The main problems have been the sprawl of equipment (note the tanks, dosers, auto-topoff, scattered about in the photo below), the low height of the shelves, which limits lighting options, and the cramped nature of the shelf unit, which makes maintaining or replacing tanks difficult. I also wanted a bigger sump, mostly to have a little more volume to prevent floods. To be honest, the photo makes it look even worse than it was, because I had moved a cabinet in preparation for the new system, leaving controllers and power supplies lying in a pile on a temporary shelf. Nonetheless, the system was long past due for an upgrade.
It took a few weeks to decide exactly how much space I could afford, and how to design the new shelves to accommodate existing tanks and allow flexibility in future configurations. I finally settled on a 60 X 16 inch footprint, which would accommodate the 15 and 20 gallon tanks on the top, plus a little extra space. It would be smaller than the space made available by the removal of one file cabinet and the old slug system, giving a little elbow room for maintenance and repair. I decided on 48 inch height. Enough for two shelves for tanks, and a bottom shelf for a sump. Three rows of tanks, a sump level, plus ample height for lights would just be too tall for me to reach easily. My experience with the current system has taught me that more tanks is not necessarily better, The second shelf would have room for a couple of 10-gallon tanks, or various combinations of 5- and 10-gallon tanks for smaller-scale experiments. The dosers and controllers would be on the bottom shelf with the sump, protecting them from splash, and making the system almost completely self-contained. By necessity, the chiller will have to be off to the side in order to move heat away from the tanks.
I decided to build the frame from 2X3 studs, and use 1/2″ plywood for the shelves. The studs should be plenty strong to support the 5 foot shelf, and 2X4s would be overkill and make the system that much heavier. The weight of the shelves is transmitted to the floor by 2X3s that run from the bottom of one shelf support to the top of the next. There is a second set of vertical 2X3s going all the way from the top shelf to the floor, providing more stability and support.
For paint, I chose a latex semi-gloss. I hope I don’t regret not using marine paint, but I am hoping that the primer plus three coats applied over the course of a week will be adequately waterproof. I tried to match the color of the walls in the office, but it turned out a bit more blue than I had intended. The piece of plywood on the back provides a surface for attaching controllers, power supplies, dosing pumps and drain brackets.
In order to simplify moving tanks in and out, I installed a 2″ drain with 8 openings along the bottom shelf, and a 3/4″ supply pipe with barbed valves along the top shelf. Installing and removing a tank will be as simple as connecting a supply hose and placing a flexible drain hose from the tank into a drain opening.
Then came the hard work of moving everything over. After Joanna pointed out that the shelves would not fit in the Jetta, I reserved a U-haul pickup truck, and we moved it from home to the office. Then it was simply a matter of spending 10 or so hours reinstalling plumbing, draining and moving tanks, setting up lights and pumps, mounting dosers and controllers, fussing with details, and cleaning up the resulting mess.
I am very happy with the results. My office is less cluttered, every aspect of the system is more accessible, the electronics are better protected from splash, and I don’t have to climb on a chair to work on the top tank. The Neptune Apex controller became a little buggy during the process, but I can again control and monitor the system remotely after a few reboots. The leak detection module is still not fully functional, so I am keeping fingers crossed that there will be no floods, large or small, until it is fixed.
One happy development is that the Bryopsis growing on the eggcrate in the 15-gallon tank (upper right in the photo above) has started to take off. Expect photos of that, plus a new shipment of marine plants, in the next day or so. Who knows, maybe there will once again be slugs in the Box of Slugs.
Back from Bonaire, with a fresh puzzle.
In research, as in life, there are things that don’t make sense. Often these things make enough sense that you ignore them, choosing to focus on other mysteries. One such little small, nagging issue is the question of what draws Elysia crispata to hard-bottom coral reefs, which lack obvious growth of green algae known to be their food. Based on observations of many years, the slugs are not in transit, most are just sitting there.
My knowledge of the habits of Elysia in the wild is far from encyclopedic, but the species I know best have hearty appetites and stay close to their food. E. diomedea are found on or near Codium in Bahia de los Angeles, and E. clarki spend most of their time face down in their food in aquaria. This tends to hold true in the literature as well. For example, E. tuca is generally found on its favorite food, Halimeda incrassata (Rasher et al., 2015, PNAS 112: 12110). As a counter example, Middlebrooks et al. (2014) found that E. clarki were often found at sites that contained few or no specimens of their food plants (Penicillus, Halimeda, Bryopsis) determined via DNA barcoding.
In any case, I think I am justified in being puzzled by the lack of an obvious food source on the reef. The photos in this post are all from a single dive at The Cliff, a site in the north-ish part of Bonaire. We found maybe a dozen slugs, most in the face-down posture, which makes them look like large blobs of colorful frosting on the rocks. The area had a lot of dead coral, which possibly serves as a substrate for the growth of food algae. However, there were no obvious growths of green algae anywhere nearby, although algae such as Halimeda and Caulerpa are plentiful in mangroves on the island.
Rather than snap a few photos of the more photogenic slugs, I thought it might be useful to document as many of the slugs as I could, with emphasis on the substrate. Honestly, what you see is what you get; there are no large clumps of Bryopsis or Halimeda hiding around the corner.
What are these gals eating? The most prominent alga is Dictyota, a brown alga which, based on known feeding habits, is an unlikely food.
Are they grazing on the little strands of green algae that can be seen if one expands the photos and looks really hard? Is this a late life stage that does not feed as much? Are E. crispata truly crawling leaves, getting their energy from photosynthesis? Is the much lighter color of E. crispata, compared to related species, like E. clarki and E. diomedea, a clue?
